MHG12889 - Shin Viaduct
No summary available.
Type and Period (1)
- RAILWAY VIADUCT (Post Medieval - 1560 AD to 1900 AD)
NH59NE 30 5784 9525 to 5792 9529
The Industrial Archaeology of Sutherland (A Scottish Highland Economy 1700-1900, pp. 70, 71-72, 73) - Sinclair B Calder, 1974
J Aitken : 19/2/2004
Oykel Viaduct [NAT]OS 1:10,000 map, 1992.
(Location cited as NH 579 953). Shin Viaduct, built 1867 for the Sutherland Rly. by engineers Joseph Mitchell and Murdoch Paterson. It is an iron-truss bridge of length 230 ft (70.1m) with two tall semicircular-arched approach spans at the S end and three at the N.J R Hume 1977.
This viaduct was built to carry the Dingwall-Wick extension of the Inverness and Ross-shire Rly across the Kyle of Sutherland; it opened to traffic on 13 April 1868, was strengthened by the addition of further ironwork in 1912-13, and remains in use.
It comprises a 280 ft (85.3m) lattice girder main span and five stone approach arches, each of 30 ft (9.1m) span.
M Smith 1994.
- --- Text/Publication/Volume: Hume, J R. 1977. The industrial archaeology of Scotland 2: The Highlands and Islands. Paper (Original). 312.
- --- Text/Publication/Volume: Nelson, G. 1990. Highland Bridges. Paperback. 154-5.
- --- Text/Publication/Volume: Smith, M. 1994. British railway bridges and viaducts. 84-5.
- --- Text/Publication/Volume: Tatlow, P. 1985. Highland railway miscellany: a pictorial record of the company's activities in the public eye and behind the scenes. pl. 138.
- --- Text/Publication/Volume: Vallance, H A. 1985. The Highland railway. 4th, extd. 35.
- --- Text/Manuscript: Calder, Sinclair B.. 1974. The Industrial Archaeology of Sutherland: A Scottish Highland Economy 1700-1900. The University of Strathclyde.
|Grid reference||Centred NH 5790 9527 (30m by 30m) (Buffered by site type)|
Related Monuments/Buildings (0)
Related Investigations/Events (0)
External Links (3)
- http://kweimar.de/Bilder_XML.php?ket=10_06 (View more information on this bridge from a website about Highland Bridges)
- http://portal.historicenvironment.scot/designation/LB279 (Online designation description (Historic Environment Scotland))
- https://canmore.org.uk/site/13013 (View RCAHMS Canmore entry for this site)
